Setting New Standards In Electro-Optical Testing

MSS-IR Single Band/Dual Band

CI System’s missile signal simulator, the MSS, tests the readiness and performance of Missile Warning Systems in the flight line, in regular routine, and close to take off. It does so by simulating the changes of the missile’s IR radiation signature from launch through flight to a target. Designed to MIL standard requirements, the MSS withstands severe field environment conditions while maintaining its reliability and accuracy.

For ease-of-use, the operator chooses the simulated missile signature from previously uploaded files. The MSS is delivered with a single or dual channel, with each channel simultaneously emitting at a different spectral band. The scenarios are emitted from the same optical exit. The scenarios are independent or can be related by a factor.

FeaturesSingle Band MSSDual Band MSS
  • Portable, compact and lightweight
  • Fast and easy to operate
  • Operates under field conditions
  • Removable MicroSD card
  • RS232/USB computer interface for maintenance
  • UV, SWIR, MWIR, LWIR bands
  • User-friendly software
  • Independent profiles for each band
Wavelength Range

265 ±5nm other wavelengths optional

Illumination Field

 Vertical : 10º ±1º

Horizontal : 10º ±1º

Maximum Radiant Intensity

4.0E-02 W/str

Dynamic Range

 10 bit

Emission Linearity

 > 95%

Temporal Resolution

5-50 msec

Number of Profile Data Files  Internal memory (Ele. Card) -10 Profiles, Each profile length 1-10 sec (Depending on Temporal Resolution) External memory (SD Card) -10 Profiles, Each profile length 50 sec
Aiming Device  Rifle Scope (Focused at 10 to 30 m) / Iron Sight

Boresight

>1 mrad between Rifle Scope / Iron Sight to OUTPUT radiation

Battery

Rechargeable Li-Ion 3.7 VDC / 5.2 Ah

Good for 200 full Length, max radiance profile

External ND Filter (Optional For different signature ranges)

Yes

External Micro SD Card

8 GB

Remote Operation

Yes

Display Interface

OLED Display 0.96" Diagonal Size

PC Interface

RS-232 / USB Adaptor

Tripod Interface

Standard¼ " - 20 UNC thread

Weight [kg]

 <2Kg (including batteries and Rifle Scope)

Laser Pointer

Optional

Dimensions [cm]

29 x 7 x 20 (H x W x L)

Operating Temperature

-10º C to +55º C

Storage Temperature

-40º C to +71º C

Environmental Condition

Rain, humidity, shock, sand, dust, transportation vibration

 Software

Windows compatible software for operation and uploading profiles into unit.

Wavelength Range

265 ±5nm other wavelengths optional

Illumination Field

 Vertical : 10º ±1º

Horizontal : 10º ±1º

Maximum Radiant Intensity

4.0E-02 W/str

Dynamic Range

 10 bit

Emission Linearity

 > 95%

Temporal Resolution

5-50 msec

Number of Profile Data Files  Internal memory (Ele. Card) -10 Profiles, Each profile length 1-10 sec (Depending on Temporal Resolution) External memory (SD Card) -10 Profiles, Each profile length 50 sec
Aiming Device  Rifle Scope (Focused at 10 to 30 m) / Iron Sight

Boresight

>1 mrad between Rifle Scope / Iron Sight to OUTPUT radiation

Battery

Rechargeable Li-Ion 3.7 VDC / 5.2 Ah

Good for 200 full Length, max radiance profile

External ND Filter (Optional For different signature ranges)

Yes

External Micro SD Card

8 GB

Remote Operation

Yes

Display Interface

OLED Display 0.96" Diagonal Size

PC Interface

RS-232 / USB Adaptor

Tripod Interface

Standard¼ " - 20 UNC thread

Weight [kg]

 <2Kg (including batteries and Rifle Scope)

Laser Pointer

Optional

Dimensions [cm]

29 x 7 x 20 (H x W x L)

Operating Temperature

-10º C to +55º C

Storage Temperature

-40º C to +71º C

Environmental Condition

Rain, humidity, shock, sand, dust, transportation vibration

 Software

Windows compatible software for operation and uploading profiles into unit.
